As an agent owner, obtaining feedback from users is a vital step in improving the effectiveness and reliability of your conversational agent. You gain valuable insights into how well your agent is performing, identify areas for enhancement, and deliver a more satisfying user experience.
In this article, you learn how to use Adaptive Cards to collect user feedback after every interaction with your agent without annoying the user. Implementing this feedback mechanism allows you to assess and enhance the quality of agent responses while ensuring user satisfaction. The feedback mechanism works for a customer support agent, an informational assistant, or any other type of conversational agent. For this example scenario, we use generated answers, but you can use the same approach for any type of response.
The final output of this example scenario shows a message after the agent's response that says, "Generated answer, please rate it."
Add a generative answer node
Open the desired topic, select the Add node icon
below the node where you want to add the generative answer node, point to Advanced, and select Generative answers.On your new Create generative answers node, for Input, select the Activity.Text system variable.
In the Create generative answers properties panel:
Select Add knowledge and add a public website, such as
https://learn.microsoft.com/.Expand the Advanced section, and create a global variable. Enter a meaningful name for the variable, such as
VarStoreAnswer. This variable stores the answer generated in response to a query from the user.Clear the Send a message box.
Add an Adaptive Card to a Question node or Message node
Add either a Question node or a Message node, and add an Adaptive Card to this node.
In the Adaptive Card properties panel, switch to Formula, and replace the default content with the following Power Fx formula:
Test your topic and save it.
Refine your feedback collection mechanism
To capture the thumbs up and down, trigger the specific topic to get more feedback. Based on up or down selections, the topic catches phrases.
Here's the YAML file to redirect to this topic to capture those responses.
kind: AdaptiveDialog
beginDialog:
kind: OnRecognizedIntent
id: main
condition: =!IsBlank(Global.VarStoreAnswer)
intent:
displayName: Untitled
actions:
- kind: SendActivity
id: sendActivity_XauhTN
activity:
attachments:
- kind: AdaptiveCardTemplate
cardContent: |-
={
type: "AdaptiveCard",
'$schema': "http://adaptivecards.io/schemas/adaptive-card.json",
version: "1.5",
body: [
{
type: "Container",
items: [
{
type: "TextBlock",
text: Global.VarStoreAnswer,
wrap: true
}
]
},
{
type: "Container",
items: [
{
type: "ColumnSet",
columns: [
{
type: "Column",
width: "90",
items: [
{
type: "TextBlock",
text: "Generated answer, please rate it",
wrap: true,
size: "Small",
color: "Accent"
}
]
},
{
type: "Column",
width: "5",
items: [
{
type: "Image",
width: "15px",
height: "15px",
selectAction: {
type: "Action.Submit",
data: "This generated answer wasn't useful"
}
}
]
},
{
type: "Column",
width: "5",
items: [
{
type: "Image",
width: "15px",
height: "15px",
selectAction: {
type: "Action.Submit",
data: "This generated answer was useful"
}
}
]
}
]
}
]
}
]
}
