展開して、既存のスケール セットのトラステッド起動とロールバック (必要な場合) へのアップグレードをサポートする完全なサンプル ARM テンプレートを表示します。
{
"$schema": "https://schema.management.azure.com/schemas/2019-04-01/deploymentTemplate.json#",
"contentVersion": "1.0.0.0",
"parameters": {
"vmSku": {
"type": "string",
"defaultValue": "Standard_D2s_v3",
"metadata": {
"description": "Size of VMs in the VM Scale Set."
}
},
"sku": {
"type": "string",
"defaultValue": "2022-datacenter-azure-edition",
"allowedValues": [
"2022-datacenter-azure-edition"
],
"metadata": {
"description": "The Windows version for the VM. This will pick a fully patched image of this given Windows version."
}
},
"vmssName": {
"type": "string",
"maxLength": 61,
"metadata": {
"description": "String used as a base for naming resources. Must be 3-61 characters in length and globally unique across Azure. A hash is prepended to this string for some resources, and resource-specific information is appended."
}
},
"instanceCount": {
"type": "int",
"defaultValue": 2,
"maxValue": 100,
"minValue": 1,
"metadata": {
"description": "Number of VM instances (100 or less)."
}
},
"adminUsername": {
"type": "string",
"metadata": {
"description": "Admin username on all VMs."
}
},
"adminPassword": {
"type": "securestring",
"metadata": {
"description": "Admin password on all VMs."
}
},
"___location": {
"type": "string",
"defaultValue": "[resourceGroup().___location]",
"metadata": {
"description": "Location for all resources."
}
},
"publicIpName": {
"type": "string",
"defaultValue": "myPublicIP",
"metadata": {
"description": "Name for the Public IP used to access the virtual machine Scale set."
}
},
"publicIPAllocationMethod": {
"type": "string",
"defaultValue": "Static",
"allowedValues": [
"Dynamic",
"Static"
],
"metadata": {
"description": "Allocation method for the Public IP used to access the virtual machine set."
}
},
"publicIpSku": {
"type": "string",
"defaultValue": "Standard",
"allowedValues": [
"Basic",
"Standard"
],
"metadata": {
"description": "SKU for the Public IP used to access the virtual machine Scale set."
}
},
"dnsLabelPrefix": {
"type": "string",
"defaultValue": "[toLower(format('{0}-{1}', parameters('vmssName'), uniqueString(resourceGroup().id)))]",
"metadata": {
"description": "Unique DNS Name for the Public IP used to access the virtual machine Scale set."
}
},
"healthExtensionProtocol": {
"type": "string",
"defaultValue": "TCP",
"allowedValues": [
"TCP",
"HTTP",
"HTTPS"
]
},
"healthExtensionPort": {
"type": "int",
"defaultValue": 3389
},
"healthExtensionRequestPath": {
"type": "string",
"defaultValue": "/"
},
"overprovision": {
"type": "bool",
"defaultValue": false
},
"upgradePolicy": {
"type": "string",
"defaultValue": "Manual",
"allowedValues": [
"Manual",
"Rolling",
"Automatic"
]
},
"maxBatchInstancePercent": {
"type": "int",
"defaultValue": 20
},
"maxUnhealthyInstancePercent": {
"type": "int",
"defaultValue": 20
},
"maxUnhealthyUpgradedInstancePercent": {
"type": "int",
"defaultValue": 20
},
"pauseTimeBetweenBatches": {
"type": "string",
"defaultValue": "PT5S"
},
"securityType": {
"type": "string",
"defaultValue": "TrustedLaunch",
"allowedValues": [
"Standard",
"TrustedLaunch"
],
"metadata": {
"description": "Security Type of the Virtual Machine."
}
},
"encryptionAtHost": {
"type": "bool",
"defaultValue": false,
"metadata": {
"description": "This property can be used by user in the request to enable or disable the Host Encryption for the virtual machine or virtual machine Scale set. This will enable the encryption for all the disks including Resource/Temp disk at host itself. The default behavior is: The Encryption at host will be disabled unless this property is set to true for the resource."
}
}
},
"variables": {
"namingInfix": "[toLower(substring(format('{0}{1}', parameters('vmssName'), uniqueString(resourceGroup().id)), 0, 9))]",
"addressPrefix": "10.0.0.0/16",
"subnetPrefix": "10.0.0.0/24",
"virtualNetworkName": "[format('{0}vnet', variables('namingInfix'))]",
"subnetName": "[format('{0}subnet', variables('namingInfix'))]",
"loadBalancerName": "[format('{0}lb', variables('namingInfix'))]",
"natPoolName": "[format('{0}natpool', variables('namingInfix'))]",
"bePoolName": "[format('{0}bepool', variables('namingInfix'))]",
"natStartPort": 50000,
"natEndPort": 50119,
"natBackendPort": 3389,
"nicName": "[format('{0}nic', variables('namingInfix'))]",
"ipConfigName": "[format('{0}ipconfig', variables('namingInfix'))]",
"imageReference": {
"2022-datacenter-azure-edition": {
"publisher": "MicrosoftWindowsServer",
"offer": "WindowsServer",
"sku": "[parameters('sku')]",
"version": "latest"
}
},
"extensionName": "GuestAttestation",
"extensionPublisher": "Microsoft.Azure.Security.WindowsAttestation",
"extensionVersion": "1.0",
"maaTenantName": "GuestAttestation",
"maaEndpoint": "[substring('emptyString', 0, 0)]",
"uefiSettingsJson": {
"secureBootEnabled": true,
"vTpmEnabled": true
},
"rollingUpgradeJson": {
"maxBatchInstancePercent": "[parameters('maxBatchInstancePercent')]",
"maxUnhealthyInstancePercent": "[parameters('maxUnhealthyInstancePercent')]",
"maxUnhealthyUpgradedInstancePercent": "[parameters('maxUnhealthyUpgradedInstancePercent')]",
"pauseTimeBetweenBatches": "[parameters('pauseTimeBetweenBatches')]"
}
},
"resources": [
{
"type": "Microsoft.Network/virtualNetworks",
"apiVersion": "2022-05-01",
"name": "[variables('virtualNetworkName')]",
"___location": "[parameters('___location')]",
"properties": {
"addressSpace": {
"addressPrefixes": [
"[variables('addressPrefix')]"
]
},
"subnets": [
{
"name": "[variables('subnetName')]",
"properties": {
"addressPrefix": "[variables('subnetPrefix')]"
}
}
]
}
},
{
"type": "Microsoft.Network/publicIPAddresses",
"apiVersion": "2022-05-01",
"name": "[parameters('publicIpName')]",
"___location": "[parameters('___location')]",
"sku": {
"name": "[parameters('publicIpSku')]"
},
"properties": {
"publicIPAllocationMethod": "[parameters('publicIPAllocationMethod')]",
"dnsSettings": {
"domainNameLabel": "[parameters('dnsLabelPrefix')]"
}
}
},
{
"type": "Microsoft.Network/loadBalancers",
"apiVersion": "2022-05-01",
"name": "[variables('loadBalancerName')]",
"___location": "[parameters('___location')]",
"sku": {
"name": "[parameters('publicIpSku')]",
"tier": "Regional"
},
"properties": {
"frontendIPConfigurations": [
{
"name": "LoadBalancerFrontEnd",
"properties": {
"publicIPAddress": {
"id": "[resourceId('Microsoft.Network/publicIPAddresses', parameters('publicIpName'))]"
}
}
}
],
"backendAddressPools": [
{
"name": "[variables('bePoolName')]"
}
],
"inboundNatPools": [
{
"name": "[variables('natPoolName')]",
"properties": {
"frontendIPConfiguration": {
"id": "[resourceId('Microsoft.Network/loadBalancers/frontendIPConfigurations', variables('loadBalancerName'), 'loadBalancerFrontEnd')]"
},
"protocol": "Tcp",
"frontendPortRangeStart": "[variables('natStartPort')]",
"frontendPortRangeEnd": "[variables('natEndPort')]",
"backendPort": "[variables('natBackendPort')]"
}
}
]
},
"dependsOn": [
"[resourceId('Microsoft.Network/publicIPAddresses', parameters('publicIpName'))]"
]
},
{
"type": "Microsoft.Compute/virtualMachineScaleSets",
"apiVersion": "2022-03-01",
"name": "[parameters('vmssName')]",
"___location": "[parameters('___location')]",
"sku": {
"name": "[parameters('vmSku')]",
"tier": "Standard",
"capacity": "[parameters('instanceCount')]"
},
"properties": {
"virtualMachineProfile": {
"storageProfile": {
"osDisk": {
"createOption": "FromImage",
"caching": "ReadWrite"
},
"imageReference": "[variables('imageReference')[parameters('sku')]]"
},
"osProfile": {
"computerNamePrefix": "[variables('namingInfix')]",
"adminUsername": "[parameters('adminUsername')]",
"adminPassword": "[parameters('adminPassword')]"
},
"securityProfile": {
"encryptionAtHost": "[parameters('encryptionAtHost')]",
"securityType": "[parameters('securityType')]",
"uefiSettings": "[if(equals(parameters('securityType'), 'TrustedLaunch'), variables('uefiSettingsJson'), null())]"
},
"networkProfile": {
"networkInterfaceConfigurations": [
{
"name": "[variables('nicName')]",
"properties": {
"primary": true,
"ipConfigurations": [
{
"name": "[variables('ipConfigName')]",
"properties": {
"subnet": {
"id": "[resourceId('Microsoft.Network/virtualNetworks/subnets', variables('virtualNetworkName'), variables('subnetName'))]"
},
"loadBalancerBackendAddressPools": [
{
"id": "[resourceId('Microsoft.Network/loadBalancers/backendAddressPools', variables('loadBalancerName'), variables('bePoolName'))]"
}
],
"loadBalancerInboundNatPools": [
{
"id": "[resourceId('Microsoft.Network/loadBalancers/inboundNatPools', variables('loadBalancerName'), variables('natPoolName'))]"
}
]
}
}
]
}
}
]
},
"extensionProfile": {
"extensions": [
{
"name": "HealthExtension",
"properties": {
"publisher": "Microsoft.ManagedServices",
"type": "ApplicationHealthWindows",
"typeHandlerVersion": "1.0",
"autoUpgradeMinorVersion": false,
"settings": {
"protocol": "[parameters('healthExtensionProtocol')]",
"port": "[parameters('healthExtensionPort')]",
"requestPath": "[if(equals(parameters('healthExtensionProtocol'), 'TCP'), null(), parameters('healthExtensionRequestPath'))]"
}
}
}
]
},
"diagnosticsProfile": {
"bootDiagnostics": {
"enabled": true
}
}
},
"orchestrationMode": "Uniform",
"overprovision": "[parameters('overprovision')]",
"upgradePolicy": {
"mode": "[parameters('upgradePolicy')]",
"rollingUpgradePolicy": "[if(equals(parameters('upgradePolicy'), 'Rolling'), variables('rollingUpgradeJson'), null())]",
"automaticOSUpgradePolicy": {
"enableAutomaticOSUpgrade": true
}
}
},
"dependsOn": [
"[resourceId('Microsoft.Network/loadBalancers', variables('loadBalancerName'))]",
"[resourceId('Microsoft.Network/virtualNetworks', variables('virtualNetworkName'))]"
]
},
{
"condition": "[and(equals(parameters('securityType'), 'TrustedLaunch'), and(equals(variables('uefiSettingsJson').secureBootEnabled, true()), equals(variables('uefiSettingsJson').vTpmEnabled, true())))]",
"type": "Microsoft.Compute/virtualMachineScaleSets/extensions",
"apiVersion": "2022-03-01",
"name": "[format('{0}/{1}', parameters('vmssName'), variables('extensionName'))]",
"___location": "[parameters('___location')]",
"properties": {
"publisher": "[variables('extensionPublisher')]",
"type": "[variables('extensionName')]",
"typeHandlerVersion": "[variables('extensionVersion')]",
"autoUpgradeMinorVersion": true,
"enableAutomaticUpgrade": true,
"settings": {
"AttestationConfig": {
"MaaSettings": {
"maaEndpoint": "[variables('maaEndpoint')]",
"maaTenantName": "[variables('maaTenantName')]"
}
}
}
},
"dependsOn": [
"[resourceId('Microsoft.Compute/virtualMachineScaleSets', parameters('vmssName'))]"
]
}
]
}
![[概要] ページのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-click-security-type.png)
![[信頼された起動セキュリティの種類] ドロップダウンのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-apply-security-type.png)
![[概要] ページのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-click-security-type.png#lightbox)
![[信頼された起動セキュリティの種類] ドロップダウンのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-apply-security-type.png#lightbox)
![[Standard security type]\(標準セキュリティの種類\) ドロップダウンのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-rollback.png)
![[Standard security type]\(標準セキュリティの種類\) ドロップダウンのスクリーンショット。](media/trusted-launch/virtual-machine-scale-sets-portal-rollback.png#lightbox)
